1 / 4
The base instrument operates from 5 kHz to 1 GHz and can be upgraded seamlessly to 3 GHz via software keycode options.
Features an ultra-low noise floor with a typical DANL of < –142 dBm (without preamplifier) and < –158 dBm, typ. –165 dBm (with preamplifier).
Measures high-power signals up to +30 dBm (1 W). Resolution bandwidth (RBW) ranges from 1 Hz to 3 MHz for resolving fine spectral details.
Equipped with a 10.1-inch color WXGA display (1366 × 768 pixels). It is 26% larger and delivers 160% higher resolution than instruments in its class.
Supports wired Ethernet and wireless Wi-Fi. Remotely controllable via R&S Instrument View (Windows) and R&S Mobileview (iOS/Android).
Expand functionality with R&S®FPC-K7 modulation analysis, R&S®FPC-K43 receiver mode, and R&S®FPC-K55 advanced measurement packages.
| Specification | Description |
|---|---|
| Frequency Range | 5 kHz - 3 GHz (upgradable, base model is 5 kHz - 1 GHz) |
| Frequency Resolution | 1 Hz |
| Marker Resolution | 0.1 Hz |
| Displayed Average Noise Level (DANL) | < –142 dBm, typical –150 dBm (without preamplifier); < –158 dBm, typical –165 dBm (with preamplifier) |
| Third-Order Intercept (TOI / IP3) | > +7 dBm (measured) |
| Level Measurement Uncertainty (at 100 MHz) | < 0.3 dB (+20 °C to +30 °C) |
| Resolution Bandwidth (RBW) | 1 Hz - 3 MHz |
| Maximum Input Power | Up to +30 dBm |
| Input Impedance | 50 Ω (nominal) |
| Display Type | WXGA |
| Display Size | 10.1-inch (25.6 cm) |
| Display Resolution | 1366 × 768 pixels |
| Interfaces | LAN, 2x USB, Wi-Fi (optional) |
| Dimensions (without feet) | 396 mm × 147 mm × 178 mm |
| Dimensions (with feet) | 396 mm × 156 mm × 185 mm |
| Weight | 3 kg |
| Operating Temperature | Minimum: +10 °C | Maximum: +40 °C |
| Power Supply | AC 100 - 240 V or DC 28 V |
Dimensions (without feet): 396 mm × 147 mm × 178 mm
Dimensions (with feet): 396 mm × 156 mm × 185 mm
Weight: 3 kg (compact and portable)
Battery Parameters: Equipped with lithium battery
Delivery information typically includes delivery times, shipping methods, packaging, etc., which may vary depending on the seller and the location of purchase.
The standard base instrument provides a frequency range from 5 kHz to 1 GHz. It can be easily upgraded up to 3 GHz via software keycode options without requiring hardware modifications.
The analyser is equipped with a 10.1-inch color WXGA screen (1366 × 768 pixels), which is 26% larger and offers 160% higher resolution than competing instruments in its class.
It offers a displayed average noise level (DANL) of < –142 dBm (typ. –150 dBm) without a preamplifier, and < –158 dBm (typ. –165 dBm) when the preamplifier is engaged.
Yes, it supports both wired Ethernet (LAN) and wireless Wi-Fi connectivity. Remote control and measurements can be performed using R&S Instrument View for Windows or the R&S Mobileview app for iOS and Android.
The unit weighs only 3 kg and measures 396 mm × 147 mm × 178 mm (without feet). It can operate on standard AC 100 - 240 V, DC 28 V, or via its equipped lithium battery.
The analyser supports optional packages including R&S®FPC-K7 modulation analysis software, R&S®FPC-K43 receiver mode software, and R&S®FPC-K55 advanced measurement software.
