Reduce the chance of releasing products that are prone to errors and malfunctions by using an oscilloscope that shows the most accurate, detailed information. The MXR B-Series is built on the same high-performance benchmark as the MXR A, but it has more recent hardware-accelerated technologies that reduces test time.
The MXR B-Series boasts speedier hardware along with standard capabilities like a 50 MHz frequency response analyzer, an integrated 50 MHz arbitrary waveform generator, and Keysight's cutting-edge InfiniiScan Event Identification Software.
With an oscilloscope that produces reliable results, the MXR B-Series' automated analysis capabilities, extra-low front-end noise, and uncompromising performance allow you to test more quickly, save time to market, and design without sacrificing quality.
Equipped with enhanced hardware acceleration and a 1,000,000 waveforms/second update rate to shorten debug and validation cycles.
Includes standard 50 MHz frequency response analyzer, arbitrary waveform generator, and InfiniiScan Event Identification Software.
Extra-low front-end noise with advanced automated analysis delivers exact, repeatable signals to prevent field failures.
Additional Available Options: 20 MHz arbitrary waveform generator, 3-digit voltmeter, serial trigger and analysis, and mask testing.
| Bandwidth | 4 Channels | 8 Channels |
|---|---|---|
| 500 MHz | MXR054B | MXR058B |
| 1 GHz | MXR104B | MXR108B |
| 2 GHz | MXR204B | MXR208B |
| 2.5 GHz | MXR254B | MXR258B |
| 4 GHz | MXR404B | MXR408B |
| 6 GHz | MXR604B | MXR608B |
| Category | Parameter | Specification Details |
|---|---|---|
| Weight | Frame | 4-channel models: 13.75 kg (30.3 lbs) 8-channel models: 14.50 kg (32.0 lbs) |
| Shipping | 4-channel models: 20.95 kg (46.2 lbs) 8-channel models: 21.90 kg (48.3 lbs) |
|
| Dimensions | Height | 327 mm (12.9 in) with feet retracted |
| Width | 443 mm (17.5 in) | |
| Depth | 223 mm (8.8 in) including knobs and rear feet |
KEYSIG~1.PDF
Download DocumentThe MXR B-Series maintains the high-performance benchmark of the MXR A while integrating speedier, hardware-accelerated technologies designed to reduce overall test duration and eliminate product malfunctions prior to release.
The MXR B-Series offers bandwidth options spanning 500 MHz, 1 GHz, 2 GHz, 2.5 GHz, 4 GHz, and 6 GHz, available across both 4-channel and 8-channel hardware configurations.
Standard equipment includes a 50 MHz frequency response analyzer, an integrated 50 MHz arbitrary waveform generator, and Keysight's InfiniiScan Event Identification Software for streamlined anomaly discovery.
The instrument provides a maximum sample rate of 5 GSa/s, an update rate of 1,000,000 waveforms per second, and exclusive zone triggering capabilities to isolate complex signals quickly.
Available upgrade options include an additional 20 MHz arbitrary waveform generator, a 3-digit voltmeter, protocol-specific serial trigger and decode analysis, and compliant mask testing packages.
The unit measures 327 mm high (feet retracted), 443 mm wide, and 223 mm deep. Frame weights are 13.75 kg (4-channel) and 14.50 kg (8-channel), with total packaged shipping weights of 20.95 kg and 21.90 kg respectively.
