Overview
You may increase productivity when sourcing and measuring DC voltage and current into the device under test (DUT) using the Keysight N6705C DC power analyzer. Up to four sophisticated power supplies can be used with the N6705C DC power analyzer: a digital multimeter (DMM), scope, arb, and data recorder.
With the N6705C DC power analyzer, all functions and measurements are on the front panel, so there's no need to write and debug scripts to handle a bunch of instruments. Use the Keysight PathWave BenchVue BV9200 control and analysis software to gain even more control and analysis capabilities.
New advanced data analysis tools, automation capabilities, and an upgraded user interface are all characteristics of the BV9200 PathWave BenchVue control and analysis software. The N6705C is fully programmable via GPIB, USB, LAN, and LXI when automated bench setups are required.
Custom configurations are available for the N6705C DC power analyzer to satisfy your power supply and analysis needs. Up to four DC power modules and 600 W of total DC output power can be accommodated by its four-slot mainframe.
Key Features
- Ideal for R&D procurement to gauge DC voltage and current entering the DUT.
- Operate common functions via dedicated physical controls.
- Visualize complex data on a large color graphic display.
- Enjoy flexible programming through GPIB, LAN, USB; compliant with LXI standards.
Frequently Asked Questions (FAQ)
What instruments are integrated into the Keysight N6705C DC Power Analyzer?
The N6705C combines up to four power supplies, a digital multimeter (DMM), an oscilloscope, an arbitrary waveform generator (arb), and a data recorder into a single integrated unit.
How many modules and what output capacity can the mainframe support?
The mainframe features a four-slot architecture accommodating up to four DC power or electronic load modules, delivering a total maximum DC output power of up to 600 W.
Can the N6705C be integrated into automated test setups?
Yes, it is fully programmable and compliant with LXI Class C standards, offering GPIB, USB 2.0, and 10/100 LAN connectivity for automated systems.
Is PC programming required to take basic measurements?
No, all core functions and measurement capabilities are accessible directly from the physical front-panel controls and displayed on its large color screen without requiring custom code or scripts.
What software is available for advanced analysis?
The Keysight PathWave BenchVue BV9200 (including PW9252A and PW9253A options) provides advanced control, data analysis tools, automation, and battery emulation capabilities.
What are the input power specifications for operating the unit?
The unit supports universal AC inputs of ~100 VAC to 240 VAC at 50/60/400 Hz, with a power consumption rating of 1440 VA.
